Honda 2016 CRF1000L Africa Twin: Full English Language Press Release and Specifications

072415middle1

Following our story yesterday, this morning MD received a press release from American Honda providing details on the 2016 CRF1000L Africa Twin, which will be in U.S. dealer showrooms in early 2016 (no pricing available at present).

As reported yesterday, the new Africa Twin features a 998 cc parallel twin engine, which should be quite smooth given the 270° crank, and “biaxial primary balance shafts”.

Honda went to great lengths to make the engine compact and light, using tricks learned from its design of motocross engines. The frame is steel, not aluminum, and the tire sizes are 21″ front and 18″ rear. The spoked wheels do not allow the use of tubeless tires, unlike Yamaha’s Super Tenere, for example.

With roughly 5 gallons of fuel, Honda claims a 503 pound wet weight for the manual transmission version and 534 pounds for the DCT/ABS version, with advanced automatic transmission.

The Africa Twin features very serious braking capabilities, together with fully adjustable fork and preload adjustable shock, as detailed below.  Here is the full press release, followed by English language specifications for the new Honda CRF1000L Africa Twin:

TORRANCE, Calif., July 24, 2015 – Honda is pleased to announce further technical details on the new CRF1000L Africa Twin, which will be in Honda showrooms across the United States in early 2016. Like its celebrated forerunners, the CRF1000L Africa Twin is thoroughly equipped for true adventure, with a potent engine and dynamic chassis ready to explore continents, on- or off-road.

From the start of the CRF1000L Africa Twin project there was one motorcycle that consistently impressed with its balance of usability, poise and handling, on the road and in the dirt—the seminal XRV750 Africa Twin. It proved a worthwhile benchmark, even when set against today’s myriad choice of adventure motorcycles. The machine that now bears its name shares no common parts with the old model but it inherits the full the essence and spirit of what made the XRV750 Africa Twin so good.

The “true adventure” approach starts with the engine, which has to perform in off-road situations as well as on-road long-range touring and all points in between. The CRF1000L Africa Twin’s 998cc parallel-twin power plant draws heavily on Honda’s off-road race experience with the CRF250R/450R competition machines, and uses the same four-valve Unicam head design for compact overall dimensions. A lightweight cast camshaft—using the same materials as that on the CBR1000RR—operates the valve train, and twin spark plugs fire the fuel/air mixture in each combustion chamber.

072415middle2

Strong and linear power and torque deliver instant response anywhere in the rev-range—accompanied by a satisfying, characterful deep growl as rpm rises. A 270° phased crankshaft gives the power delivery a distinct character as well, delivering excellent feel for rear-wheel traction. Biaxial primary balance shafts cancel vibration.

The engine’s short height contributes to the CRF1000L Africa Twin’s excellent ground clearance—another prerequisite for a true adventure machine. It also uses clever packaging of componentry to both dynamic and aesthetic effect. The water pump is housed within the clutch casing, and the water and oil pumps are driven by a shared balancer shaft. Further reducing engine size is the lower crankcase design, which stores the oil and houses the pressure-fed pump.

The lightweight six-speed manual gearbox uses the same shift-cam design as found on the CRF250R/450R to ensure positive changes and is equipped with an assist slipper clutch.

For the CRF1000L Africa Twin’s chassis, three key attributes—highlights of the original XRV750—were targeted: off-road performance, touring comfort and the everyday agility that makes for a great all-rounder or day-to-day commuter.

A steel semi-double cradle frame provides a balance of highway touring capability—even while fully loaded—genuine off-road performance, agility and sheer strength. Mass centralization—with items like the battery packaged at the rear of the cylinder head—contributes to a low center of gravity.

072415middle3

The long-travel Showa inverted fork is fully adjustable and features dual radial-mount Nissin four-piston brake calipers and 310mm “wave” style floating discs. The Showa rear shock has hydraulic spring-preload adjustment. Like the CRF450R Rally, the CRF1000L Africa Twin uses 21- and 18-inch front and rear spoke wheels, wearing 90/90-21 and 150/70-18 tires.

Following its design theme of “unlimited adventure,” the Africa Twin is styled with minimum bodywork in a tough, lightweight form that offers both weather protection for the rider and a slim, agile feel. Dual headlights maintain the original’s signature presence and the seat height adjusts .8 inches to either 34.3 or 33.5 inches. A large 4.96 gallon fuel tank—coupled with the engine’s fuel efficiency—stretches the distances between refueling stops.

To tailor the overall electronics package to capably tackle any conditions on- or off-road, the Honda Selectable Torque Control (HSTC) system offers three levels of control, and it is possible for the rider to turn off the ABS system for the rear wheel. (HSTC and ABS not available on base version; equipped as standard on DCT/ABS version.)

The CRF1000L Africa Twin will be available in two color options: Red/Black/White Dakar Rally and Silver.

072415top-i

Dual Clutch Transmission (DCT)

Honda’s unique Dual Clutch Transmission (DCT) will be available as an option on the CRF1000L Africa Twin, with the use of a common crankcase keeping the width the same as the manual transmission version.

It features the standard manual mode—allowing the rider to operate gear shifts through triggers on the left handlebar—and two automatic modes. D mode offers the best balance of fuel efficiency and comfort cruising. S mode gives extra levels of sport performance, with three different shift patterns to choose from: S1, S2 and S3.

In certain situations on the road, such as during low-speed maneuvers, the DCT partially disengages the clutch to reduce the effect that quick throttle movements have on the chassis. Of course, DCT for the CRF1000L Africa Twin is also fully equipped to operate in an adventure environment. With the G switch on in any riding mode, the connection between the throttle and the rear wheel is more direct, which can be desirable in certain off-road situations.

Further new functionality for the DCT system comes in the form of incline detection. During ascents, upshifts are delayed in order to allow a higher rpm to be held; on descents, downshifts happen earlier to enable better engine braking.

072415bottom

Technical Specifications: 2016 Honda CRF1000L Africa Twin

Engine Type Liquid-cooled 4-stroke 8-valve Parallel Twin with 270° crank and Unicam
Engine Displacement 998cc
Bore x Stroke 92.0 x 75.1 mm
Clutch Wet, multi-plate with coil springs, aluminum cam assist and slipper clutch
Final Drive O-ring sealed chain
Gearbox/Transmission Type Constant mesh 6-speed manual / 6-speed DCT with on- and off-road riding modes
Honda Selectable Torque Control System (HSTC) HSTC 3-levels + switch-off (DCT/ABS model only, not on STD model)
Frame Type Steel semi-double cradle type with high-tensile strength steel rear sub-frame
Turning Radius 8’2”
Curb Weight 503 lb. (STD), 534 lb. (DCT/ABS)
Fuel Capacity 4.96 gallons
Length x Width x Height 91.9 x 34.4 x 58.1 inches (STD), 91.9 x 36.6 x 58.1 inches (DCT/ABS)
Wheelbase 62.0 inches
Seat Height (STD position / Low position) 34.3/33.5 inches
Ground Clearance 9.8 inches
ABS system type ABS 2-channel with rear ABS off switch (DCT/ABS model only, not on STD model)
Front Brakes 310mm dual wave floating hydraulic disc with aluminum hub and radial fit 4-piston calipers and sintered metal pads
Rear Brake 256mm wave hydraulic disc with 2-piston caliper and sintered metal pads. Also Lever-Lock Type Parking Brake System on DCT/ABS model
Front Wheel Wire spoke with aluminum rim
Rear Wheel Wire spoke with aluminum rim
Front Rim Size 21M/C x MT2.15
Rear Rim Size 18M/C x MT4.00
Front Tire 90/90-R21 tube type
Rear Tire 150/70-R18 tube type
