Honda EICMA Concepts Display Possible Design Directions

112415top-i

Honda R&D Europe trotted out a couple of interesting concepts in Milan last week. Both bikes are based on the engine and chassis found in the CBR650F, a versatile machine already tested by MD.

The street-oriented CB4 Concept shows off the beautiful, flowing exhaust headers from the engine and styles the machine in a street fighter look that we find appealing. Notable are the billet triple clamps holding the upside down fork and the radial-mount front brake calipers. The exhaust treatment on the CB4 provides a very aggressive look, as does the abbreviated rear end.

The other concept is the CB Six50. This is a scrambler-style machine (although the low slung exhaust seems an odd choice) with knobby tires mounted on spoked wheels. The handlebar on the CB Six50 looks like it came straight off a dirt bike, and it holds a thin digital display. The treatment of the headlight assembly is interesting and unique.

As far as we know, both concepts are merely design exercises with no plans for production.

112415middle1

112415middle2

112415bottom
